ICRC / IFRC Shelter Tool Kit
- 01x BAG, duffle type, coated polyethylene 180g/m², 1300x400mm
- 01x NAILS, ROOFING, 75mm (3″), hot galva. + rubber washer, 0.5kg
- 01x NAILS, hot galvanised iron, for wood, 40mm, (1.1/2″)
- 01x NAILS, hot galvanised iron, for wood, 7.5cm (3″)
- 01x TIE WIRE, galvanised, diam. 1.5 mm, 25m, roll
- 01x MEASURING TAPE, tailor type, PVC coated polyester, 20mm x 3m
- 01x SHEARS, straight, for metal sheet, semi-hard 1mm max., 255mm
- 01x CLAW HAMMER, carpenter type, 750g, wood handle
- 02x NEEDLE, stitching, curved, 127mm x 1.8mm, hole 1x7mm
- 01x HANDSAW, for timber, 400mm blade
- 30x ROPE, POLYPROPYLENE, diam. 3mm, twisted, green 30x ROPE, POLYPROPYLENE, black, diam. 12mm, twisted
- 01x HOE, with long handle, large type
- 01x MACHETTE, approx. length 500mm, wooden handle
- 01x SHOVEL, round point with Y handle, total length approx.1m
| Materials | |
| Rope | Polypropylene, black, 12mm diam., twisted / Diameter: 12mm +/- 0.5mm. Length: 30m. Weight: 1.9kg. Number of strand: 3 minimum Type: twisted.Material: polypropylene, no recycled fibres, UV stabilized. Colour: black. Tensile strength: 300kg. |
| Handsaw | For timber / Type & dimensions: carpenter handsaw, 400-450mm blade, lacquered, overall length 550mm +/-50mm. Blade thickness: 1mm +/- 0.05mm, protected against oxidation. Blade protection: Protective cardboard, teeth protection with hard, plastic cover. Seal type: laminated carbon steel, hardened and tempered. Number of teeth: 7-teeth per inch. Quality of make: Soft edges but no dents, cracks or broken teeth. Hardness Rockwell C: 45 to 50 HRC for the whole blade, 48 to 52 HRC at teeth level. Carbon content: 0.47% to 0.55%. Manganese content: 0.5% to 0.8%. Handle: Wooden dismountable handle, minimum 3 fixations, polished varnish hardwood, large 85x35mm opening for hand comfort when wearing gloves. Optional 45/90° square. Moisture minimum 10%, maximum 15%. Strength testing: With the blade inserted into a 10mm-wide slot to a depth equal to 1/3 the blade’s length, but not exceeding 150mm, a deflection of 90° is applied 25 times in each direction without breakage or permanent set to the blade. |
| Nail | For Roof Sheets. Galvanized with watertight rubber washer. / Type: Iron nails, made of polished low-carbon steel, cold processed, not heat treated except for galvanization. / Shape: Spiral rolled or twisted shank, sealed umbrella-type spring-head. Corrosion treatment: hot-dip galvanized at 300g/m2 +/-10%. Tensile strength: minimum 650N/mm2. Accessories: attached rubber washer with each nail. Dimensions (+/- 5%): shank: 75×3.6mm, head diameter: 20mm minimum. Rubber washer: diameter 26mm x thickness 2mm. Packing: packed in a strong, thick PE 130g/m² plastic bag, which can be zipped or locked. Net weight: 0.5kg |
| Shovel* | Round point with Y handle. / Material: Pressed carbon-steel, hardened and tempered. Corrosion protection: black paint. Quality of make: no excess metal in the eye, no dents, no cracks, soft edges. Hardness Rockwell C: 35 minimum to 48 maximum HRC. Carbon content: 0.4% to 0.6%. Manganese content: 0.5% to 1%. Silicone: 0.37% maximum. Phosphorus & Sulphur: 0.06% maximum. Dimensions, full piece: 295 x 225mm +/-15mm. Hole diameter: front side 36mm, back side 40mm, +/-5%. Weight: 1kg +/- 50g, without handle. |
| Hoe | With long handle. Material: hot forged carbon steel, hardened and tempered, at a maximum the hardened zone should reach halfway up the back of the blade. Corrosion protection: black paint. Quality of make:no excess metal in the eye, no dent on the cutting edge, reinforced head with a rib from the eye to the middle of the blade length. Hardness Rockwell C: 35 minimum to 48 maximum HRC in hardened zone of the blade. Carbon content: 0.5% to 0.8%. Manganese content: 0.6% to 1.2%. Silicone: 0.37% maximum. Phosphorus & Sulphur: 0.06% maximum. Dimensions, full piece: 180 x 310 mm +/-10mm including the eye. Hole diameter: high raised neck, front side 43 mm, back side 48 mm+/-2mm. Weight: 1.250kg +/- 150g, without handle, depending on the type of hoe. |
| Machete | Type: curved blade, 405mm/16″, lacquered against oxidation, overall length 55cm. Blade thickness: 2.5mm thick with 3 grooves that runs the full length of the blade to key in the handle. Handle: wooden handle with 3 aluminium rivets plus washers. Material: hot forged carbon steel, hardened and tempered, hardened throughout the entire blade, but remains normal past the first rivet hole. Protection: blade packed in carton pocket for protection. Quality of make: no dent on the cutting edge. Hardness Rockwell C: 45 minimum to 50 maximum HRC near cutting edge, test 3 positions along the cutting edge. Carbon content: 0.48% to 0.65%. Manganese content: 0.6% to 1%. Silicone: 0.37% maximum. Phosphorus & Sulphur: 0.03% maximum. |
| Shears | Straight, for metal sheet, semi-hard 0.8mm max., 260mm. Type: tin snips for intensive use and easy maintenance. Make: each blade and handle forged as one piece, symmetrical blades. Capacity: up to 0.8mm semi-hard iron sheet. Material: hot forged carbon steel, hardened and tempered, special treatment applied to the blade edge. Rustproof: protected against corrosion with special paint. Dimensions: overall length: 250 to 260mm. Maintenance: dismountable in 2 parts only, with bolt and self locking nut. |
| Materials | |
| Nail | Iron, for wood, large. Type: iron nails, made of polished low-carbon steel, cold processed, not heat treated except for galvanization. Rustproof: hot dip galvanized at 300g/m2 +/-10%. Tensile strength:minimum 650N/mm2. Shape: flat, smooth,circular head; plain, round shank and diamond point. Dimensions (+/-5%): ll length x diameter: 75×3.6mm, head diameter: 7.7mm. Packing: packed in strong, thick PE 130g/m² plastic bag, which can be zipped or locked. Net weight: 0.5kg per type. |
| Nail | Iron, for wood, small. Type: iron nails, made of polished low carbon steel, cold processed, not heat treated except for galvanisation.Rustproof: hot dip galvanised at 300g/m2 +/-10%. Tensile strength: minimum 650N/mm2. Shape: ll flat smooth circular head, plain round shank and diamond point. Dimensions (+/-5%): ll length x diameter: 40×2.2mm, head diameter: 5mm to 5.5mm. Packing: packed in strong thick PE 130g/m² plastic bag, which can be zipped or locked. Net weight: 0.5kg per type. |
| Tire wire | Galvanised, diam. 1.5 mm, 25m, roll. Materialll low carbon steel, hot dip galvanised with minimum 40g/m2, binding /tie wire. Quantity: roll of 25m. Dimension: diameter 1.5mm +/-5%. Tensile strength: minimum 340 N/mm² to Maximum 500N/mm. |
| Claw hammer | Type: Carpenter hammer, head and handle, hammer head with flat and claw side, as per ISO15601, except for the pull-apart test force.Material: high-carbon steel head, treated to achieve a martensitic structure, with dressed striking faces. Quality of make: smooth surface and edges with no dents or cracks; no excess metal in the eye. Weight of the hammer: Total weight 750g +/- 50g (equivalent to 700g minimum, 800g maximum). Hardness Rockwell C: 50 minimum to 58 maximum HRC on striking faces. Hardness Rockwell C: 35 maximum HRC closed to the eye. |
| Polyethylene | 1 bag per kit. Material: Standard ICRC/IFRC tarpaulin, white, without the bands. Type: Square rectangular base duffle bag with 6 aluminium |
| Bag | or galvanised steel eyelets and a 10mm PP rope for closing that can also act as a shoulder handle. Dimensions: Total length 1250mm. Final packed maximum dimension 1200x300x150mm +/-10mm |
| Cardboard fold | 1 per kit. Material: Double-walled corrugated cardboard.Type: One or several pieces of cardboard in which the complete kit is securely packed before being placed in the bag. The cardboard folds on the 2 long sides and one short side. Dimensions: To fit in the outer bag. Sealing: Strapped with 2 heat-sealed 10mm minimum plastic straps. Quality: Loaded cartons should withstand 1m-high stacking on pallets, and several handlings (hand and forklift) without damage. Palletising: The pallets (wood or metal) are made or reinforced in such a way that allows 2 levels stacking (stacking up to 2m high), without any damage for the kits and the kit packaging. |
