Technical specifications
Dimensions
| Total size | 1.50 x 2.00 m |
| Weight | 200 – 400 gsm |
Low Thermal Blankets
- ICRC/IFRC Standard
- Resistant to fire, thermal, and air flow
- Minimum 1.5 TOG for indoor use, on a bed, in a house with heating facilities
- 1.5m x 2m low synthetic blankets made of virgin fibers from polyester, knitted, and dry raised on both sides (ISO 1833 on dry weight, 100% virgin polyester)
- Recommended for indoor use, on a bed, in a house with heating facilities
Materials
- All our materials are UV-proof, waterproof, rotproof and fire resistant.
- Marking and logo customized to your requirements.
| Materials | |
|---|---|
| Blankets | 100% virgin fibers from polyester or acrylic, knitted or woven, dry raised both sides, ISO C1833 on dry weight, color grey. Some may included in the yarns. |
| Thickness | ISO 5084, 3.5mm minimum (1KPa on 2000 mm2) |
| Tensile strength | ISO 13934-1: 250N warp and weft minimum |
| After washing | ISO 13934-1 & ISO 6330: Max 5% warp and weft after 3 consecutive machine washes at 30°C and one flat drying |
| Shrinkage | ISO 6330: Max 5% warp and weft after 3 consecutive machine washes at 30°C and one flat drying |
| Weight loss after washing | Max 5% after 3 consecutive machine washes at 30°C and one flat drying |
| Thermal resistance | ISO 11092: TOG 1.5 (or 0.15m² K/W) minimum, rounded to the nearest 0.01, passed on samples picked from compressed bales. |
| After opening of the bale, the blanket shall be dry tumbled in a dryer for 15 minutes (without any other load), at a temperature of
|
|
| less than 30°C and at least 24 hours by flat lying | |
| Air flow resistance | ISO 9237 under 100Pa pressure drop: Max 1500 L/m²/s |
| Fire resistance | ISO 12952 – 1: Resistance to cigarette. No ignition. |
| ISO 12952 – 2: Resistance to flame. No ignition. | |
| Organoleptic test | No bad smell, no skin irritation, no dust. 4 |
| Finish | Whipped seam at 10mm from the edge with 10-13 stitches/ 100mm or stitched ribbon or hemmed on 4 sides. Corners can be |
| round up to 100mm radius, or square. |
Packing & shipping
| Packing unit | ICRC/IFRC |
| Content and dimension per bale | 20 pcs / bale |
| 80 x 53 x 47 cm | |
| Weight per bale | Min. 15 Kgs |
| Content and dimension per pallet | 80 pcs / pallet |
| 112 x 78 x 108 cm | |
| Weight per pallet | Min. 74 Kgs |
Estimated loadability
| Container | With customized pallet | Without pallet |
| 20’ GP container | 28 pallets (2,240 pcs) | 140 bales (2,800 pcs) |
| 40’ DC container | 60 pallets (4,800 pcs) | 300 bales (6,000 pcs) |
| 40’ HC container | 60 pallets (4,800 pcs) | 375 bales (7,500 pcs) |
